313-9078
23.83mm Inner Diameter Control Valve Tube Assembly
Rigid hydraulic line delivering fluid between the main pump and control valve stack.
Description
Pre-bent steel line routed between the hydraulic pump and control valve group. Clean bends maintain proper volumetric flow rates, which keeps spool response predictable when metering boom, bucket, or steering circuits. Pre-installed end fittings and…
Overview
Pre-bent steel line routed between the hydraulic pump and control valve group. Clean bends maintain proper volumetric flow rates, which keeps spool response predictable when metering boom, bucket, or steering circuits. Pre-installed end fittings and seal interfaces mate flush against port blocks to prevent oil weepage under continuous system pressure.
Features
- 23.83 mm inner diameter tube geometry
- Pre-formed bends match factory routing
- Flanged and sealed ends prevent fluid leaks
- Handles continuous cyclic hydraulic pressures
Applications
Hydraulic valve manifold connections and high-pressure supply circuits on heavy machinery.
Specifications
| Brand | Caterpillar |
|---|
Related parts
103.83mm Inner Diameter Ring Seal
7T-5594
Similar part
6.83mm Inner Diameter Spacer
9P-2553
Similar part
14.83mm Inner Diameter Auxiliary Lines Tube
290-8082
Similar part
1.83mm Inner Diameter Fuel Lines
9Y-0148
Similar part
1.83mm Inner Diameter Fuel Injection Line Assembly
