TURNING PLATE

320 732 68 TURNING PLATE is essentially a sacrificial wear surface, designed to take the brunt of the friction. You'll usually find these bolted or sometimes even welded onto the main structural components, like the feed beam channels or the guides for a rod changer. Its main gig is to keep the expensive metal-on-metal contact from happening between the moving parts – think the drill string carriage or the rod magazine – and the main frame of the rig. It just wears out so the bigger, pricier stuff doesn't.

When these plates start to wear thin, you’ll definitely notice things getting a bit sloppy. If it’s on a feed beam, for example, the drill carriage might start to develop some noticeable play, leading to uneven bit wear or even binding up during a feed. Another dead giveaway is usually a new grinding or squealing noise, especially under load, as the surfaces it was supposed to protect start rubbing directly. I’ve seen rod changers get completely jammed because these plates were so worn the rods weren't lining up right anymore.

Swapping these out isn’t typically a complex job, but it’s one of those maintenance items that often gets put off until a bigger issue pops up. When you're pulling the old one off, always take a good look at the fasteners – sometimes they’re loose, or the mounting holes get wallowed out if the plate's been shifting. And don't just slap the new one on; give the mating surface a thorough check for any gouges or damage that might have happened before the replacement. A little bit of appropriate grease, if the application calls for it, can also extend the life a fair bit.
