CORNER-RH

CORNER-RH 5580 0108 13 Serving as a key structural element, this right-hand corner piece holds critical parts of the feed assembly together. Its main job is to provide a solid, correctly aligned mounting point, typically where the side and front plates of the feed beam meet. By maintaining the feed's geometry, it ensures the drifter travels straight and true along the beam during the entire drill cycle.

Any damage or wear to this corner piece directly impacts drilling accuracy and equipment health. For instance, if the corner is bent even slightly, it will misalign the drifter, causing accelerated wear on the slide bars, the drifter cradle, and the drill string itself. This misalignment increases friction, reduces penetration speed, and can lead to premature failure of expensive drilling tools.

Look for signs of cracking, especially around the mounting holes, or any visible bending. A common symptom of a failing corner is the drifter binding or moving unevenly on the feed. During routine maintenance, check that all mounting bolts are tight. If you find any damage, replace the part promptly to avoid a chain reaction of wear on other feed components.
