BEARING CUP

In Stock

The 560 174 63 BEARING CUP is a critical component for supporting rotating shafts under heavy loads. As the outer race for a tapered roller bearing, it provides a durable, precision surface that ensures smooth operation in gearboxes, feed systems, and other high-stress pivot points.

Quantity:

Description

Full Technical Description

560 174 63 BEARING CUP Serving as the stationary outer race in a bearing assembly, this cup provides a hardened track for the rollers. It is designed to handle both radial and axial forces, making it essential for components like the drifter's rotation unit or the wheel assemblies on the feed cradle. Its precise geometry ensures that shafts and gears are properly aligned and can rotate with minimal friction.

A worn or pitted BEARING CUP directly impacts the machine's reliability and drilling accuracy. Increased friction and play within the bearing can lead to overheating and eventual seizure of the rotating part. For instance, if this cup fails in the feed system, the drifter can become misaligned on the beam, causing excessive wear on the guide rails and poor hole straightness.

Listen for grinding noises or check for excessive heat from bearing housings during inspections, as these are common signs of failure. When replacing a bearing, always install a new cup and cone together as a matched set. Ensure the housing is clean before carefully pressing the new cup into place to prevent damage.
