BG00419837a

PLATE, BACK

In Stock

The BG 004 198 37A PLATE, BACK is a fundamental structural component for the rear of the rock drill. It provides a secure housing for internal mechanisms and manages the flow of hydraulic fluid, ensuring the drifter operates with correct pressure and power.

Quantity:

Description

Full Technical Description

BG 004 198 37A PLATE, BACK This component functions as the rear enclosure for the drifter body, sealing the main cylinder and directing hydraulic oil to the piston and rotation motor. It contains critical fluid passages that are essential for generating the percussive force and turning the drill steel. The PLATE, BACK also serves as the primary mounting point for high-pressure hoses and accumulators, making its structural integrity vital for the entire drilling system.

A failure in the PLATE, BACK, such as a crack or a warped sealing surface, can lead to significant performance loss. Internal pressure leaks between circuits will rob the piston of its impact energy, resulting in slower drilling and increased stress on other components. External leaks not only waste expensive hydraulic oil but also pose a serious slip hazard for personnel working around the rig.

Look for oil weeping from the rear of the drifter or a gradual drop in penetration rate as early signs of a problem. During service, carefully inspect for any hairline cracks, especially around the threaded ports. When installing a new PLATE, BACK, always use fresh seals and tighten the retaining bolts in a cross pattern to ensure it seats evenly without distortion.
